Compact linear bushing KBC-12 for 12 mm shaft - Bosch Rexroth R065801200

Bosch Rexroth ✓ Original product Brand new Made in Germany

Compact linear bushing KBC-12 by Bosch Rexroth for shafts of 12 mm diameter. Dynamic load capacity 870 N, static load capacity 620 N. Without wiper seals, not lubricated, weight 0.02 kg.

Net
€10.44
excl. VAT
Item BRR-R065801200
Manufacturer no. R065801200
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

Building a linear guide on hardened precision shafts calls for a bearing with a defined load capacity and low friction. The Compact linear bushing KBC-12 runs on shafts of 12 mm diameter and reaches a dynamic load capacity of 870 N with a static load capacity of 620 N. Weight: 0.02 kg.

Benefits

  • Load capacity: dynamic 730 N to 870 N, static 420 N to 620 N, depending on load direction relative to the ball rows
  • Dynamics: up to 5 m/s, acceleration up to 150 m/s²
  • Sealing and lubrication: without wiper seals, not lubricated
  • Design: Closed, series Compact
  • Clearance: Radial clearance shaft/bore h6/H7 +32 µm
  • Installation dimensions: outer diameter D = 19 mm, length 28 mm

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR065801200
Type designationKBC-12
Friction coefficient μ0.001 ... 0.004
Radial clearance shaft/bore h6/H7+32 µm
LubricationNot lubricated
Maximum permissible linear speed vmax5 m/s
Length of linear bushing28 mm
SeriesCompact
Maximum dynamic load capacity Cmax870 N
Rows of balls5
Breakaway force1.5 N
Maximum acceleration rate amax150 m/s²
Outer diameter D19 mm
Minimum static load capacity C0min420 N
Shaft diameter d12 mm
Minimum dynamic load capacity Cmin730 N
Maximum static load capacity C0max620 N
Format of linear bushingsClosed
VersionNormal
Radial clearanceNormal radial clearance
Friction force FR0.8 N
SealWithout wiper seals
Permissible ambient temperature (min. ... max.)-10 °C ... +80 °C
Weight0.02 kg
Manufacturer Nr.R065801200
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
