Linear set (aluminum) LSAC-16-DD-G for 16 mm shaft - Bosch Rexroth R102721644

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (aluminum) LSAC-16-DD-G by Bosch Rexroth for shafts of 16 mm diameter. Dynamic load capacity 1050 N, static load capacity 570 N. Weight 0.11 kg, material number R102721644.

Net
€33.11
excl. VAT
Item BRR-R102721644
Manufacturer no. R102721644
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSAC-16-DD-G is designed for shafts of 16 mm diameter and carries 1050 N dynamic and 570 N static load. Weight: 0.11 kg.

Benefits

  • Load capacity: dynamic load capacity C = 1050 N, static load capacity C0 = 570 N
  • Dynamics: up to 5 m/s, acceleration up to 150 m/s²
  • Design: Closed, series Compact
  • Clearance: Shaft radial clearance h6 +32 µm
  • Installation dimensions: outer diameter D = 24 mm
  • Temperature range: -10 °C ... +80 °C

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR102721644
Type designationLSAC-16-DD-G
Maximum permissible linear speed vmax5 m/s
Static load capacity C0570 N
SeriesCompact
Shaft radial clearance h6+32 µm
Breakaway force2 N
Maximum acceleration rate amax150 m/s²
Outer diameter D24 mm
Shaft diameter d16 mm
Format of linear bushingsClosed
Dynamic load capacity C1050 N
VersionNormal
Friction force FR1 N
Permissible ambient temperature (min. ... max.)-10 °C ... +80 °C
Weight0.11 kg
Manufacturer Nr.R102721644
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
