Linear set (aluminum) LSACT-16-DD-NR-G for 16 mm shaft - Bosch Rexroth R102921634

Name: Linear set (aluminum) LSACT-16-DD-NR-G for 16 mm shaft - Bosch Rexroth R102921634
Brand: Bosch Rexroth
SKU: BRR-R102921634
Price: 81.90 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (aluminum) LSACT-16-DD-NR-G by Bosch Rexroth for shafts of 16 mm diameter. Dynamic load capacity 1180 N, static load capacity 920 N. Weight 0.24 kg, material number R102921634.

Net

€81.90

excl. VAT

Item BRR-R102921634

Manufacturer no. R102921634

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSACT-16-DD-NR-G is designed for shafts of 16 mm diameter and carries 1180 N dynamic and 920 N static load. Weight: 0.24 kg.

Benefits

Load capacity: dynamic load capacity C = 1180 N, static load capacity C0 = 920 N
Dynamics: up to 5 m/s, acceleration up to 150 m/s²
Design: Closed, series Compact
Clearance: Shaft radial clearance h6 +32 µm
Material: Corrosion-resistant
Installation dimensions: outer diameter D = 24 mm

Technical data

Manufacturer	Bosch Rexroth
Manufacturer part number	R102921634
Type designation	LSACT-16-DD-NR-G
Maximum permissible linear speed vmax	5 m/s
Static load capacity C0	920 N
Series	Compact
Shaft radial clearance h6	+32 µm
Breakaway force	2 N
Maximum acceleration rate amax	150 m/s²
Outer diameter D	24 mm
Shaft diameter d	16 mm
Static longitudinal moment load capacity ML0	18 Nm
Format of linear bushings	Closed
Dynamic load capacity C	1180 N
Version	Corrosion-resistant
Friction force FR	1 N
Permissible ambient temperature (min. ... max.)	-10 °C ... +80 °C
Weight	0.24 kg
Manufacturer Nr.	R102921634
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
