Linear set (aluminum) LSATOE-A-50-DD for 50 mm shaft - Bosch Rexroth R103465020

Name: Linear set (aluminum) LSATOE-A-50-DD for 50 mm shaft - Bosch Rexroth R103465020
Brand: Bosch Rexroth
SKU: BRR-R103465020
Price: 506.51 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (aluminum) LSATOE-A-50-DD by Bosch Rexroth for shafts of 50 mm diameter. Dynamic load capacity 20300 N, static load capacity 13240 N. Weight 5.21 kg, material number R103465020.

Net

€506.51

excl. VAT

Item BRR-R103465020

Manufacturer no. R103465020

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSATOE-A-50-DD is designed for shafts of 50 mm diameter and carries 20300 N dynamic and 13240 N static load. Weight: 5.21 kg.

Benefits

Load capacity: dynamic load capacity C = 20300 N, static load capacity C0 = 13240 N
Dynamics: up to 3 m/s, acceleration up to 150 m/s²
Design: TOE - Tandem, open, adjustable, series Super A (with self-alignment feature)
Clearance: Radial clearance set to zero clearance on an h5 shaft (lower limit) at the factory
Installation dimensions: outer diameter D = 75 mm
Temperature range: -10 °C ... +80 °C

Technical data

Manufacturer	Bosch Rexroth
Manufacturer part number	R103465020
Type designation	LSATOE-A-50-DD
Static load capacity C0	13240 N
Series	Super A (with self-alignment feature)
Breakaway force	10 N
Outer diameter D	75 mm
Shaft diameter d	50 mm
Static longitudinal moment load capacity ML0	415 Nm
Format of linear bushings	TOE - Tandem, open, adjustable
Dynamic load capacity C	20300 N
Dimension B1	132 mm
Friction force FR	4 N
Maximum permissible linear speed vmax	3 m/s
Maximum acceleration rate amax	150 m/s²
Radial clearance	set to zero clearance on an h5 shaft (lower limit) at the factory
Dynamic longitudinal moment load capacity ML	630 Nm
Permissible ambient temperature (min. ... max.)	-10 °C ... +80 °C
Weight	5.21 kg
Manufacturer Nr.	R103465020
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
