Linear set LSAO-B-16-DD by Bosch Rexroth, material number R103781620. The static load capacity is 830 N.
Linear set LSAO-B-16-DD - Bosch Rexroth R103781620
BOSCH REXROTH
Original product
Net price (excl. VAT)
€52.73
Item
BRR-R103781620
Manufacturer no.
R103781620
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R103781620
Country of originGermany
ConditionNew
Article
BRR-R103781620
Frequently Bought Together
-
This Item:
€52.73
-
Linear set LSG-A-12-DD - Bosch Rexroth R106561240
€35.40
-
Linear set LSADR1T-25-WV-2000 - Bosch Rexroth R109922588
€632.96
Total price
Linear set LSAO-B-16-DD by Bosch Rexroth, material number R103781620. The static load capacity is 830 N. Permissible values are up to 3 m/s travel speed and 150 m/s² acceleration. The weight is 0.18 kg.
Technical data
| Maximum permissible linear speed vmax | 3 m/s |
|---|---|
| Type | Linear set |
| Static load capacity C0 | 830 N |
| Series | Super B (no self-alignment feature) |
| Shaft radial clearance h6 | <prefix>+</prefix>28<suffix></suffix> |
| Breakaway force | 2 N |
| Maximum acceleration rate amax | 150 m/s² |
| Outer diameter D | 26 mm |
| Shaft diameter d | 16 mm |
| Linear guide type | Linear bushing and shaft |
| Format of linear bushings | O - Open |
| Dynamic load capacity C | 1500 N |
| Friction force FR | 1 N |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 0.18 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer Nr. | R103781620 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
