Linear set (steel) LSRE-60-DD for 60 mm shaft - Bosch Rexroth R107626020

Name: Linear set (steel) LSRE-60-DD for 60 mm shaft - Bosch Rexroth R107626020
Brand: Bosch Rexroth
SKU: BRR-R107626020
Price: 1750.75 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (steel) LSRE-60-DD by Bosch Rexroth for shafts of 60 mm diameter. Dynamic load capacity 29500 N, static load capacity 34100 N. Weight 35.08 kg, material number R107626020.

Net

€1,750.75

excl. VAT

Item BRR-R107626020

Manufacturer no. R107626020

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSRE-60-DD is designed for shafts of 60 mm diameter and carries 29500 N dynamic and 34100 N static load. Weight: 35.08 kg.

Benefits

Load capacity: dynamic load capacity C = 29500 N, static load capacity C0 = 34100 N
Dynamics: up to 2 m/s, acceleration up to 50 m/s²
Design: OE - Open, adjustable, series Radial, open
Clearance: Radial clearance set to zero clearance on an h5 shaft (lower limit) at the factory
Installation dimensions: outer diameter D = 110 mm
Temperature range: -20 °C ... +80 °C

Technical data

Manufacturer	Bosch Rexroth
Manufacturer part number	R107626020
Type designation	LSRE-60-DD
Maximum permissible linear speed vmax	2 m/s
Static load capacity C0	34100 N
Series	Radial, open
Breakaway force	48 N
Maximum acceleration rate amax	50 m/s²
Outer diameter D	110 mm
Shaft diameter d	60 mm
Format of linear bushings	OE - Open, adjustable
Dynamic load capacity C	29500 N
Radial clearance	set to zero clearance on an h5 shaft (lower limit) at the factory
Friction force FR	16 N
Permissible ambient temperature (min. ... max.)	-20 °C ... +80 °C
Weight	35.08 kg
Manufacturer Nr.	R107626020
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
