Linear set (steel) LSGF-A-40-DD for 40 mm shaft - Bosch Rexroth R108164040

Images are examples, some edited with AI. The technical data are authoritative. AI notice

Linear set (steel) LSGF-A-40-DD for 40 mm shaft - Bosch Rexroth R108164040

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (steel) LSGF-A-40-DD by Bosch Rexroth for shafts of 40 mm diameter. Dynamic load capacity 8240 N, static load capacity 4350 N. Weight 1.67 kg, material number R108164040.

Net
€117.73
excl. VAT
Item BRR-R108164040
Manufacturer no. R108164040
Save Compare
Question about this item
Datasheet (PDF) User manual 5 documents, all under Downloads
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSGF-A-40-DD is designed for shafts of 40 mm diameter and carries 8240 N dynamic and 4350 N static load. Weight: 1.67 kg.

Benefits

  • Load capacity: dynamic load capacity C = 8240 N, static load capacity C0 = 4350 N
  • Dynamics: up to 3 m/s, acceleration up to 150 m/s²
  • Design: F - Flange, series Super A (with self-alignment feature)
  • Clearance: Shaft radial clearance h6 +50 µm
  • Installation dimensions: outer diameter D = 62 mm
  • Temperature range: -10 °C ... +80 °C

Technical data

ManufacturerBosch Rexroth
Manufacturer part numberR108164040
Type designationLSGF-A-40-DD
Maximum permissible linear speed vmax3 m/s
Static load capacity C04350 N
SeriesSuper A (with self-alignment feature)
Shaft radial clearance h6+50 µm
Breakaway force8 N
Maximum acceleration rate amax150 m/s²
Outer diameter D62 mm
Shaft diameter d40 mm
Format of linear bushingsF - Flange
Dynamic load capacity C8240 N
Friction force FR3 N
Permissible ambient temperature (min. ... max.)-10 °C ... +80 °C
Weight1.67 kg
Manufacturer Nr.R108164040
GPSR manufacturer informationBosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
