Linear set (steel) LSSDR1T-50-WV-2000 for 50 mm shaft - Bosch Rexroth R109725088

Name: Linear set (steel) LSSDR1T-50-WV-2000 for 50 mm shaft - Bosch Rexroth R109725088
Brand: Bosch Rexroth
SKU: BRR-R109725088
Price: 1688.65 EUR
Availability: InStock

Bosch Rexroth ✓ Original product Brand new Made in Germany

Linear set (steel) LSSDR1T-50-WV-2000 by Bosch Rexroth for shafts of 50 mm diameter. Dynamic load capacity 15000 N, static load capacity 12940 N, torque up to 167 Nm. Weight 47.6 kg, material number R109725088.

Net

€1,688.65

excl. VAT

Item BRR-R109725088

Manufacturer no. R109725088

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

A linear set saves you designing your own bearing housing: linear bushing and housing arrive ready to install and are simply bolted to the mounting structure. The Linear set LSSDR1T-50-WV-2000 is designed for shafts of 50 mm diameter and carries 15000 N dynamic and 12940 N static load. Weight: 47.6 kg.

Benefits

Load capacity: dynamic load capacity C = 15000 N, static load capacity C0 = 12940 N
Torque transmission: dynamic torsional moment load capacity Mt = 167 Nm
Dynamics: up to 3 m/s, acceleration up to 150 m/s²
Design: T - Tandem, series Torque
Installation dimensions: outer diameter D = 75 mm
Temperature range: -10 °C ... +80 °C

Technical data

Manufacturer	Bosch Rexroth
Manufacturer part number	R109725088
Type designation	LSSDR1T-50-WV-2000
Maximum permissible linear speed vmax	3 m/s
Mass m (kg/m)	15.3 kg/m
Dynamic torsional moment load capacity Mt	167 Nm
Static load capacity C0	12940 N
Series	Torque
Maximum acceleration rate amax	150 m/s²
Outer diameter D	75 mm
Shaft diameter d	50 mm
Format of linear bushings	T - Tandem
Dynamic load capacity C	15000 N
Permissible ambient temperature (min. ... max.)	-10 °C ... +80 °C
Weight	47.6 kg
Manufacturer Nr.	R109725088
GPSR manufacturer information	Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
