Linear set LSSDR2T-40-WV-2000 by Bosch Rexroth, material number R109754088. The static load capacity is 8700 N.
Linear set LSSDR2T-40-WV-2000 - Bosch Rexroth R109754088
BOSCH REXROTH
Original product
Net price (excl. VAT)
€1,136.99
Item
BRR-R109754088
Manufacturer no.
R109754088
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R109754088
Country of originGermany
ConditionNew
Article
BRR-R109754088
Frequently Bought Together
-
This Item:
€1,136.99
-
Linear set LSGF-M-40 - Bosch Rexroth R108114000
€116.96
-
Linear set LSHDR2T-20-WV-900 - Bosch Rexroth R072252085
€439.59
Total price
Linear set LSSDR2T-40-WV-2000 by Bosch Rexroth, material number R109754088. The static load capacity is 8700 N. Permissible values are up to 3 m/s travel speed and 150 m/s² acceleration. The weight is 0.1 kg.
Technical data
| Maximum permissible linear speed vmax | 3 m/s |
|---|---|
| Mass m (kg/m) | 9.8 kg/m |
| Type | Linear set |
| Shaft diameter d | 40 mm |
| Dynamic torsional moment load capacity Mt | 140 Nm |
| Static load capacity C0 | 8700 N |
| Linear guide type | Linear bushing and shaft |
| Format of linear bushings | T - Tandem |
| Dynamic load capacity C | 10200 N |
| Series | Torque |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Maximum acceleration rate amax | 150 m/s² |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Outer diameter D | 62 mm |
| Weight | 0.1 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Manufacturer Nr. | R109754088 |
|---|---|
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
