Kugelwagen CS KWE-045-SLH-C2-P-1 by Bosch Rexroth, material number R205F42220. Size 45, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Pre-lubricated, preserved.
Bosch Rexroth R205F42220. Kugelwagen CS KWE-045-SLH-C2-P-1
BOSCH REXROTH
Original product
Net price (excl. VAT)
€82.45
Item
BRR-R205F42220
Manufacturer no.
R205F42220
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R205F42220
Country of originGermany
ConditionNew
Article
BRR-R205F42220
Frequently Bought Together
-
This Item:
€82.45
-
Bosch Rexroth R205A22320. Kugelwagen CS KWE-025-FNS-C2-H-1
€37.71
-
Bosch Rexroth R205C72320. Kugelwagen CS KWE-030-SNS-C2-H-1
€39.70
Total price
Kugelwagen CS KWE-045-SLH-C2-P-1 by Bosch Rexroth, material number R205F42220. Size 45, accuracy class P - Precise, preload class C2 - Medium preload, seal SS - Standard seal and lubrication Pre-lubricated, preserved. The dynamic load capacity is 79200 N. The static load capacity is 120000 N. Permissible values are up to 3 m/s travel speed and 250 m/s² acceleration. The weight is 4.11 kg.
Technical data
| Friction coefficient μ | 0.002 ... 0.003 |
|---|---|
| Height runner block with guide rail | 70 mm |
| Pitch T guide rail | 105 mm |
| Ball chain | Without ball chain (standard) |
| Nominal size | 45 |
| Preload class | C2 - Medium preload |
| Static load capacity C0 | 120000 N |
| Height of runner block | 60.3 mm |
| Format | SLH - slimline, long, high |
| Length of runner block | 174 mm |
| Runner block or guide rail | Runner block |
| Width of runner block | 86 mm |
| Static torsional moment load capacity Mt0 | 2780 Nm |
| Dynamic torsional moment load capacity Mt100 | 1840 Nm |
| Static longitudinal moment load capacity ML0 | 2860 Nm |
| Linear guide type | Ball rail system Compact Line |
| Version | Ball rail system |
| Accuracy class | P - Precise |
| Dimension B1 | 133.5 mm |
| Friction coefficient μ min. | 0.002 |
| Model | Compact Line ball runner block |
| Lubrication | Pre-lubricated, preserved |
| Maximum permissible linear speed vmax | 3 m/s |
| Friction coefficient μ max. | 0.003 |
| Dynamic load capacity C50 | 99800 N |
| Dimension T | 105 mm |
| Preload force | 5150 N |
| Maximum acceleration rate amax | 250 m/s² |
| Dynamic load capacity C100 | 79200 N |
| Dynamic longitudinal moment load capacity ML50 | 2380 Nm |
| Dynamic longitudinal moment load capacity ML100 | 1890 Nm |
| Dynamic torsional moment load capacity Mt50 | 2320 Nm |
| Dimension T1 min | 18 mm |
| Seal | SS - Standard seal |
| Permissible ambient temperature (min) | <prefix>-</prefix>10<suffix></suffix> °C |
| Permissible ambient temperature (max) | <prefix>+</prefix>80<suffix></suffix> °C |
| Weight | 4.11 kg |
| Permissible ambient temperature (min. ... max.) | -10 °C ... +80 °C |
| Norm | DIN ISO 14728-1 |
|---|---|
| Manufacturer Nr. | R205F42220 |
| Manufacturer | Bosch Rexroth |
| Country of Manufacture | Germany |
| Weight | 0.100000 |
| GPSR manufacturer information | Bosch Rexroth AG, Zum Eisengießer 1, DE-97816 Lohr am Main, www.boschrexroth.com |
| Article authenticity | Original product |
| Condition of article | New |
| Preload | C2 |
| Accuracy class | P - Precision |
| Position sensing | No |
