Straight Ground Cord 0.7 m, 10 mm Socket to M5 Ring Terminal, 1 Megohm - Desco 230480

A work mat only protects when it is reliably grounded. This 0.7 m straight cord connects the 10 mm stud of the mat to the ground point. The 10 mm socket contains a 1 megohm resistor (1 x 10⁶ ohms), and the other end carries a M5 ring terminal for a secure screw connection to a ground bus or earth terminal.

Key benefits

• 1 megohm resistor in the 10 mm socket, right at the mat connection.
• M5 ring terminal at the ground end, screwed down and vibration-proof.
• 2.5 mm cord diameter with PVC insulation.
• 7-end duplex tinsel copper conductor for strength and flexibility.
• Straight 0.7 m design, no spring tension on the mat.

Applications

Grounding bench and floor mats at ESD workstations. Connect each work surface individually to the ground point, never daisy-chain surfaces.

Standards

Under IEC 61340-5-1 all conductive and dissipative items in an EPA are bonded to a common ground point, as described in the IEC TR 61340-5-2 user guide. Check ground connections periodically.
