Coiled Cord Dual-Wire MagSnap 360, 1.8 m, Blue, Grey Plug, 2 x 1 Megohm - Desco 19906

With dual-wire wrist straps, the reliability of continuous monitoring depends on the coiled cord. The Desco 19906 MagSnap 360 coiled cord connects magnetically to the wristband, rotates freely through 360° and releases under load instead of breaking. Both conductors carry a 1 megohm safety resistor (±5 %), and the dual-wire design provides a redundant path-to-ground.

Key benefits

• Magnetic connection with 4.4 to 22.2 N perpendicular breakaway force eliminates intermittent failures and extends service life.
• 360° rotation between wristband and cord for freedom of motion and less strain on the wrist.
• Strain relief tested over 1 million flex cycles, 62 times the minimum requirement per ESD S1.1.
• Two 1 megohm resistors (±5 %) for a redundant path, system resistance below 3.5 x 10⁷ ohms per IEC 61340-5-1.
• Relaxed retraction coil does not tug on the arm. Date coded, UL listed.

Applications

Replacement or spare cord for operators with MagSnap 360 dual-wire wrist straps at workstations with dual-wire continuous monitors or 3.5 mm grounding jacks.

Standards

Meets the required limits of ANSI/ESD S20.20 and the requirements of ANSI/ESD S1.1, system resistance per IEC 61340-5-1. Test wrist strap and cord daily or monitor them continuously.
