Conductive Closed-Cell Pin-Insertion Foam, Cross-Linked PE, 250 x 250 x 6 mm - Desco 241570

For long-term storage of sensitive components, ESD protection is only half the story: the foam must not crumble and must stay chemically stable. This black cross-linked polyethylene foam with fine closed cells is firm enough to hold pins securely, sheds no particles and brings inserted leads to the same potential with a surface resistance of 1 x 10³ to 1 x 10⁴ ohms. The piece measures 250 x 250 mm and is 6 mm thick.

Key benefits

• Equipotential bonding: inserted leads share the same potential, Rs 1 x 10³ to 1 x 10⁴ ohms, static decay under 0.2 s.
• Closed-cell and non-particulating: no abrasion, no crumbs on boards or contacts.
• Highly stable chemically and physically, water absorption below 0.3 % by volume over 7 days, suited to long-term storage.
• Firm, with 55 kPa compression strength at 25 %: pins stay seated and the foam does not give way.
• Easy to work: can be cut, routed and vacuum formed to make shaped inserts.

Applications

Inserts for conductive boxes and drawers, long-term storage of ICs and connectors, shaped component nests by routing or vacuum forming, use up to 95 °C.

Standards

Surface resistance per DIN 53482, volume resistance per ASTM D991-89, static decay per EIA 541 appendix F. Under EN 61340-5-2, untreated foams are not permitted as packaging in the EPA, and this foam is permanently conductive.
