Dissipative PE Cushioning Foam, Closed-Cell, Sheets 950 or 1900 x 1000 mm, 6 to 30 mm - Desco

On worksurfaces, shelves and carts, assemblies should rest on a soft surface without building up charge. This closed-cell cross-linked PE foam is compounded for permanent dissipative properties and reaches a point-to-point resistance of 1 x 10⁴ to below 1 x 10¹¹ ohms. Placed on a grounded ESD worksurface, it is grounded through that surface. Sheets come in 950 x 1000 and 1900 x 1000 mm, with thickness from 6 to 30 mm chosen for the cushioning needed.

Key benefits

• Dissipative with Rp-p from 1 x 10⁴ to < 1 x 10¹¹ ohms per ANSI/ESD STM11.11, within the EN 61340-5-1 worksurface limit.
• Permanent ESD properties that do not degrade, unlike pink antistatic foams without defined dissipative values.
• Grounds itself: placed on a grounded ESD worksurface, the foam couples electrically, so no separate ground cord is needed.
• Closed-cell cross-linked structure: does not flake, slough or contaminate products.
• Cushion grade at 30 kg/m³ and Shore hardness 61 (OO scale): the non-abrasive surface protects against shock and scratches.

Applications

Cushioning layer on ESD worksurfaces, shelves and cart shelves, lining for containers and totes used in internal transport, and cut pieces as interleaves in packaging.

Standards

Meets the EN 61340-5-1 worksurface limit and the surface resistance range of packaging table 4, tested per IEC 61340-2-3 and ANSI/ESD STM11.11. Mechanical values per BS EN ISO 7214 and BS EN ISO 868.
