Humidity Indicator Cards, 3 Spots 30-40-50 %, Can of 125 - Desco 3HIC125

Moisture sensitive parts such as SMD ICs are packed in moisture barrier bags with desiccant. When the bag is opened, it must be clear at a glance whether the contents stayed dry. These humidity indicator cards show the relative humidity the package was exposed to using 3 spots at 30, 40, 50 % RH: each spot changes from blue to pink once its level is exceeded.

Key benefits

• Blue to pink colour change, readable instantly without an instrument
• 3 indicator spots at 30, 40, 50 % RH
• Complies with MS 20003-2, MIL-I-8835, MIL-P-116
• Pre-punched holes at top and bottom for fixing
• Can of 125 protects the cards from ambient humidity until use
• Lead-free, RoHS 2 compliant, can be shipped with RoHS compliant products

Applications

Humidity monitoring in dry packs for moisture sensitive devices (MSD) together with moisture barrier bags and desiccant, at goods-in, in the SMD store and before placement. Widely used in military applications and for MIL-STD-2073 preservation packaging.

Standards

Complies with MS 20003-2, MIL-I-8835, MIL-P-116. The chemistry uses a cobalt compound without sulphur compounds.
