AC Outlet Analyser and Wrist Strap Tester, Type F (Schuko) Plug - Desco 98135

A wrist strap only protects if the outlet behind it is properly grounded. This Desco tester checks both in one unit: plugged into the outlet, it shows at once whether the wiring is correct and the equipment grounding conductor is intact. The operator then tests the wrist strap with the test switch against limits of 750 kilohms to 35 megohms.

Key benefits

• Outlet verified: green LED when wiring and ground path are correct, red LED and alarm on a fault
• One-touch wrist strap test: green LED and tone on pass, limits 750 kilohms to 35 megohms per IEC 61340-5-1 and ANSI/ESD S20.20
• Verified ground point: banana jack for the wrist strap and ground terminal for #8 ring terminals, for mats, carts and tools
• Expandable: with the 770043 Multi-Ground Hub, up to 12 ground points
• Traceable calibration: calibrated to NIST-traceable standards, certificate from the manufacturer

Applications

Daily wrist strap testing right at the workstation, combined with an outlet check. The IEC TR 61340-5-2 user guide recommends testing wrist straps that are worn daily on a daily basis. If the wrist strap LED stays off, check the fit of the band and the coil cord, then retest.

Standards

Wrist strap limits per IEC 61340-5-1 and ANSI/ESD S20.20. The unit is a tool for periodic testing as described in IEC TR 61340-5-2.
