The stroboscopic illumination of the Dino-Lite AM3715TB freezes fast running processes, for instance print on a running press. Measurement function with calibration via the supplied calibration target. Two year manufacturer warranty, shipped from Germany.
USB Edge Stroboscope Microscope VGA 20-220x High Speed - Dino-Lite AM3715TB
DINO-LITE
Original product
Net price (excl. VAT)
€399.60
Item
AM3715TB
Manufacturer no.
AM3715TB
RoHS 2011/65/EU
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.AM3715TB
EAN4712805475360
Country of originTaiwan
Customs tariff number90118000
ConditionNew
Article
AM3715TB
Frequently Bought Together
-
This Item:
€399.60
-
Metal holder with 8-10 mm stand mount for microscopes - Dino-Lite HD-M1
€44.40
-
USB 3.0 Digital Microscope 5 MP 10-220x with EDOF and Polarizer - Dino-Lite AM73915MZT
€1,141.20
Total price
The stroboscopic illumination of the Dino-Lite AM3715TB freezes fast running processes, for instance print on a running press.
What it does for you
- A VGA sensor and a 20-220x magnification range, so overview and detail come from the same device.
- Measurement function with calibration via the supplied calibration target.
- The MicroTouch trigger on the housing captures the image without shaking the camera.
Technical data
| Property | Value |
|---|---|
| Magnification | 20x ~ 220x |
| Working distance | Standard |
| Macro zoom | No |
| Lens type | Glass with anti-reflection coating |
| Sensor type | CMOS |
| Resolution | VGA (640x480) |
| Frame rate | 30 fps |
| Illumination | Stroboscopic |
| Number of LEDs | 8 |
| LEDs switchable | Yes |
| Polarizer | No |
| Infrared filter | IR cut-filter >650 nm |
| Emission filter | No |
| Diffuser cap | Yes (N3C-D included) |
| Measurement | Yes |
| Calibration | Yes |
| MicroTouch sensor | Yes |
| Magnification lock | Yes |
| Interface | USB 2.0 |
| Imaging standards | DirectShow, UVC |
| Wi-Fi | No |
| Operating system | Windows 7, 8, 10 & 11 |
| Software | DinoCapture 2.0 (Windows) |
| Housing | Composite/ plastic housing |
| Dimensions | 10.5cm (L) x 3.2cm (D) |
| Weight | 105g |
| Cable length | 1.8m |
| ESD safe | No |
| Country of origin | Taiwan |
| Warranty | 2 years European warranty |
| Regulatory approval | CE, FCC, ROHS |
| Package contents | Microscope, carry pouch, software CD, user manual, quick guide, calibration target, front cover box, USB cable, connector for external trigger |
Magnification, working distance and field of view
| Magnification | Working distance (mm) | Field of view X (mm) | Field of view Y (mm) | Depth of field (mm) |
|---|---|---|---|---|
| 20 | 60.2 | 19.5 | 15.6 | 2.5 |
| 30 | 33.5 | 13.0 | 10.4 | 1.8 |
| 40 | 20.9 | 9.8 | 7.8 | 1.5 |
| 50 | 13.9 | 7.8 | 6.3 | - |
| 100 | 4.1 | 3.9 | 3.1 | - |
| 150 | 5.6 | 2.6 | 2.1 | - |
| 200 | 9.9 | 2.0 | 1.6 | - |
| 220 | 11.9 | 1.8 | 1.4 | - |
| 220 | 11.9 | 1.8 | 1.4 | 0.1 |
Values without front cap, as published by the manufacturer.
Typical uses
- Print and textiles: halftone dots, fibre orientation, ink build-up.
- Quality control and incoming inspection: surface defects, burrs, coatings, dimensional checks.
| Certification | RoHS 2011/65/EU |
|---|---|
| ESD version | TEC |
| Manufacturer Nr. | AM3715TB |
| Manufacturer | Dino-Lite |
| Country of Manufacture | Taiwan |
| EAN | 4712805475360 |
| ESD equipment | USB Mikroskop |
| Weight | 0.105000 |
| HS-Code | 90118000 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
| Warranty | 2 years |
| Material | ABS plastic |
| Polarizer | No |
| Long Working Distance | No |
| Interface | USB 2.0 |
