DinoEye Edge USB eyepiece camera 5 MP with EDOF and C-mount - Dino-Lite AM7025X
The Dino-Lite AM7025X turns an existing stereo or transmitted light microscope into a digital camera. Measurement function with calibration via the supplied calibration target. Two year manufacturer warranty, shipped from Germany.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Dino-Lite AM7025X turns an existing stereo or transmitted light microscope into a digital camera.
What it does for you
- A 5 MP sensor and a 20x magnification range, so overview and detail come from the same device.
- Measurement function with calibration via the supplied calibration target.
- EDOF stacks images at different focus levels and so extends depth of field on uneven surfaces.
- Wireless ready: with the WF-10 adapter the microscope runs cable free on tablet and phone.
Typical uses
- Quality control and incoming inspection: surface defects, burrs, coatings, dimensional checks.
- Materials testing: fracture surfaces, welds, corrosion, microstructure.
- Laboratory and life science: labelled specimens, cell cultures, fluorescence signals.
Technical data
| Property | Value |
|---|---|
| Magnification | 20x, built-in |
| Lens type | Glass with Anti-Reflection coating |
| Sensor type | CMOS |
| Resolution | 5 Megapixel (2592x1944) |
| Frame rate | 30 fps |
| Extended depth of field (EDOF) | Yes |
| Measurement | Yes |
| Calibration | Yes |
| MicroTouch sensor | No |
| Interface | USB 2.0 |
| Imaging standards | DirectShow, UVC |
| Wi-Fi | Wireless-ready, requires the WF-10 WiFi streamer (optional) |
| Operating system | Windows 7, 8, 10 & 11, MacOS 10.12 and up |
| Software | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
| Housing | Metal body |
| Dimensions | 80 mm (H) x 32 mm (D) |
| Weight | 117 g |
| Cable length | 1.8 m |
| Country of origin | Taiwan |
| Warranty | 2 years European warranty |
| Regulatory approval | CE, FCC, ROHS |
| Package contents | DinoEye eyepiece camera, carry pouch, software CD, calibration target, user manual |
| Manufacturer | Dino-Lite |
| Manufacturer Nr. | AM7025X |
| EAN | 4712805476459 |
| HS-Code | 90118000 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Taiwan |
| Material | Metal |
| ESD version | TEC |
| ESD equipment | USB Mikroskop |
| Certification | RoHS 2011/65/EU |
| Magnification max (x) | 20 |
