DinoEye Edge USB eyepiece camera 1.3 MP with C-mount adapter - Dino-Lite AM4025X

Edge series eyepiece camera

The AM4025X streams the image of a classic microscope live to PC or Mac. With the supplied adapters it fits 23, 30 and 30.5 mm eyepiece tubes as well as a C-mount port, so even trinocular setups are digitised without altering the optics.

Key features

• 1.3 MP CMOS sensor at 1280 x 1024 pixels and up to 30 frames per second
• Adapters for 23, 30, 30.5 mm eyepieces and C-mount included
• USB 2.0 with both USB-A and USB-C cables
• Glass lens with anti-reflection coating
• Measurement, annotation and time-lapse through DinoCapture and DinoXcope

Technical data

• Sensor: 1.3 MP, 1280 x 1024 (CMOS)
• Interface: USB 2.0 (USB-A and USB-C)
• Mounting: 23 / 30 / 30.5 mm eyepiece and C-mount
• Weight: approx. 0.117 kg
• Software: DinoCapture (Windows), DinoXcope (Mac)

Applications

• Digitising stereo and trinocular microscopes
• Image documentation and measurement in lab and quality control
• Shared review on a monitor

Compatibility and contents

Adapters for 23, 30 and 30.5 mm plus C-mount included, along with USB-A and USB-C cables and DinoCapture and DinoXcope software. The effective magnification comes from the optics of the host microscope.

Origin

Made in Taiwan by AnMo Electronics.
