The Dino-Lite MEDL3H belongs to the Dino-Lite medical range and documents findings directly on the patient. The MicroTouch trigger on the housing captures the image without shaking the camera. Two year manufacturer warranty, shipped from Germany.
USB trichoscope camera VGA 10-200x - Dino-Lite MEDL3H
DINO-LITE
Original product
Net price (excl. VAT)
€1,168.83
Item
MEDL3H
Manufacturer no.
MEDL3H
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.MEDL3H
Country of originTaiwan
Customs tariff number90118000
ConditionNew
Article
MEDL3H
Frequently Bought Together
-
This Item:
€1,168.83
-
USB trichoscope camera 5 MP 10-200x with polarizer - Dino-Lite MEDL7HM
€1,168.83
-
USB podoscope camera 1.3 MP 10-50x with polarizer - Dino-Lite MEDL4FW
€1,168.83
Total price
The Dino-Lite MEDL3H belongs to the Dino-Lite medical range and documents findings directly on the patient.
What it does for you
- A VGA sensor and a 10-200x magnification range, so overview and detail come from the same device.
- The MicroTouch trigger on the housing captures the image without shaking the camera.
Technical data
| Property | Value |
|---|---|
| Magnification | 10-70x, 200x |
| Lens type | Glass with anti-reflection coating |
| Sensor type | CMOS |
| Resolution | VGA (640x480) |
| Frame rate | 30 fps |
| Illumination | White |
| Number of LEDs | 8 |
| LEDs switchable | Yes |
| Polarizer | No |
| Infrared filter | IR cut-filter >650 nm |
| Diffuser cap | No |
| Measurement | No |
| Calibration | No |
| MicroTouch sensor | Yes |
| Magnification lock | No |
| Interface | USB 2.0 |
| Imaging standards | DirectShow, UVC |
| Operating system | Windows 7, 8, 10 & 11, MacOS 10.9 and up |
| Software | DinoCapture 2.0 (Windows), DinoXcope (Mac OS) |
| Housing | Composite/plastic housing |
| Dimensions | 10.5cm (L) x 3.2cm (D) |
| Weight | 95 g |
| Cable length | 1.8m |
| Country of origin | Taiwan |
| Warranty | 2 years European warranty |
| Regulatory approval | Medical Device Class 1 - Medical Devices Regulation (EU) 2017/745 |
| Package contents | Microscope, carry pouch, software CD, ZT-Z-CC1 cap closure, user manual |
Typical uses
- Practice and clinic: documenting findings and following up on the patient.
| ESD version | TEC |
|---|---|
| Manufacturer Nr. | MEDL3H |
| Manufacturer | Dino-Lite |
| Country of Manufacture | Taiwan |
| ESD equipment | USB Mikroskop |
| Weight | 0.095000 |
| HS-Code | 90118000 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment, info@esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
| Warranty | 2 years |
| Material | ABS plastic |
| Polarizer | No |
| Interface | USB 2.0 |
| Position sensing | No |
