Soldering Iron 30 S, 30 W, 230 V - Ersa 0330KD
Universal ERSA 30 S soldering iron with 30 W power for 230 V mains operation. Robust and durable, ideal for craft, service and hobby work. Supplied with a 3.1 mm chisel-shaped Ersadur long-life tip and rubber holder disc.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The ERSA 30 S is the best-selling, time-proven universal soldering iron for craft, service and hobby applications, known worldwide for its robustness and long service life. Rated at 30 W, it reaches a maximum tip temperature of 380 °C with a heat-up time of around 120 seconds. It is supplied with a 3.1 mm chisel-shaped Ersadur long-life soldering tip (0032KD) and an easy-to-fit rubber holder disc (3N194).
Technical data
| Specification | Value |
|---|---|
| Rated power | 30 W |
| Voltage | 230 V |
| Heat-up time | 120 s |
| Max. tip temperature | 380 °C |
| Design | straight |
| Tip shape | chisel-shaped |
| Tip diameter | 3.1 mm |
| Tip coating | long-life tip (Ersadur) |
| Soldering/desoldering tip | 032 series |
| Replacement heating element | E033100 |
| Antistatic version | No |
| Operating mode | mains operation |
| RoHS compliant | Yes |
| Weight | 0.28 kg |
| Manufacturer | Ersa |
| Manufacturer Nr. | 0330KD |
| EAN | 4003008047004 |
| GPSR manufacturer information | Ersa GmbH, Leonhard-Karl-Straße 24, DE-97877 Wertheim, www.kurtzersa.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Ausführung | gerade |
| ESD version | TEC |
| ESD equipment | ESD Lötstationen |
| Certification | RoHS 2011/65/EU |
| Power (W) | 30 W |
| Tip diameter/width [mm] | 3.1 |
| Soldering tip coating | Dauerlötspitze |
| Soldering tip shape | meißelförmig |
| Heat-up time [s] | 120 |
| Operating voltage | 230 V |
| Temperature (max.) | bis 380 °C |
Downloads
Datasheet
Declaration of Conformity
