ESD drawer cabinet 27x27E, 564x572x283 mm, 2 drawers 1x50/1x150, 75 kg, KEY Lock - Lista 95.006

Built to the Lista 27 x 27 E grid, each of the 2 drawers offers 459 x 459 mm of usable area and carries 75 kg. The 1x50/1x150 mm layout suits a store where small components and bulky test equipment sit side by side, secured by the KEY Lock with interchangeable cylinder, opened and locked with a key. At just 283 mm high, the cabinet fits under a worktop or on top of a workbench.

Benefits

• Dissipative surface: All painted parts carry the dissipative paint coating developed by Lista, which drains charges in a controlled way.
• KEY Lock: The interchangeable cylinder can be swapped if a key goes missing.
• 75 kg per drawer: usable area of 459 x 459 mm per drawer, enough for heavy test equipment and tools.
• Single-drawer interlock: As standard only one drawer can be opened at a time, which keeps the cabinet stable when drawers are pulled out.

Colours

Choose the ESD colour when ordering from the following options:

• Light grey RAL 7035
• Pale grey NCS S 2403-Y
• Anthracite grey RAL 7016
• Orange NCS S 1080-Y40R

Use and combination

Typical locations are EPA areas in electronics production and at EMS providers, test and repair stations, labs and component stores. The dissipative effect depends on the cabinet being properly earthed. Lista partitioning material in the 27 x 27 E grid divides the drawers for small parts, and the cabinet can be lined up with other Lista elements of the same width.

Notes

Follow Lista's assembly instructions and loading guidelines when loading the drawers and the cabinet. The stated load capacity applies to an evenly distributed load.
