INROLED_70 LED tube light PC opal white 921 mm, IP69K, 120-277V AC - LED2WORK 115310-04

The INROLED_70 lights machines, technical plant and building services with 3340 lm from a slim tube just Ø 70 mm across. The light source is protected by a splinter-free polycarbonate tube (Ø 70 mm) with an opal-white cover.

Key benefits

• IP67/IP69K rating: sealed against water, dust and moisture, including high-pressure washdown.
• Opal-white cover for soft, homogeneous light at low weight.
• Daisy-chainable: several luminaires connect on one supply via through-wiring, up to a total current draw of 16A AC at 40 °C.
• Heat dissipation: an extruded aluminium profile carries away electronics heat and supports the rated life of over 100,000 h (L80/B10).
• Connection: via cable gland and internal WAGO terminals.
• Integrated driver: runs directly on the 120-277V AC wide-range mains.

Technical data

• Model: INROLED_70 mit PC protective tube
• Design: surface-mounted LED tube light
• Light source: SMD LED
• Total power incl. driver: ~23 W
• Power: ~21 W
• Luminous flux: 3340 lm
• Luminous efficacy: ~155 lm/W
• Light colour: 5700K 3-step MacAdam
• Colour rendering (Ra): >85
• Supply voltage: 120-277V AC ± 10%, 50-60 Hz
• Connection: cable entry, internal terminal
• Protection rating: IP67/IP69K
• Protection class: I
• Glare control: opal white
• Beam angle: 125°
• Operating temperature: -10 °C - +40 °C
• Service life: > 100.000 h (L80/B10)
• Housing material: aluminium
• Cover material: polycarbonate, splinter-free
• Protective tube: Ø 70 mm
• Length: 921 mm
• Weight: 1700 g
• Risk group (DIN EN 62471): exempt group
• Certifications: CE, UKCA
• Made in: Germany

Applications

• Interior and work-area lighting on machines and technical plant
• Logistics, conveying and warehousing
• Building and facility services

Supply and standards

Made in Germany. Mounting and dimming accessories available as options. Certifications: CE, UKCA. Exempt group per DIN EN 62471.
