120610-01. UNILED II, adjustable arm, 100° - 16W, 230V AC

Robust construction

• IP40 degree of protection, protection class III
• Opal-white plastic cover for homogeneous and shadowless illumination
• Aluminium body material, anodized in silver, heat dissipation through the main body, no burn hazard
• Aluminium spring arm, 3D head joint

Economic viability

• Exceptionally energy efficient
• Service life >60,000 operating hours (L70 / B10)
• Switching circuits do not affect the life span
• No maintenance periods
• Dimmable (version-dependant)

Optimal illumination

• 0.3W SMD LEDs, efficiency >120 lumen/Watt
• Daylight white (5,200K – 5,700K) / Ra >85 Natural white (4,000K – 4,500K) / Ra >93
• 100° beam angle
• Infinitely variable dimming with memory function using button on the lamp head
• Anti-glare through opal-white covering, shadow-free and glare-free

Features

• Lamp is mounted by means of the table clamp, additional mounting accessories optionally available
• 2 housing lengths/ratings for delivery
• 24V DC connection, M12 sensor connector with 1.5 m cable on the lamp stand. A plug-in power supply unit with 1.5 m cable for direct connection 230V AC and a table clamp are also included as part of the scope of supply.

Downloads

• LED2WORK_UNILED_II_120610-01
