UNILED II articulated-arm light width 298 mm, 5700K 10W 100-240V - LED2WORK 120610-01

LED2WORK ✓ Original product Brand new Made in Germany

UNILED II articulated-arm LED light, luminaire width 298 mm, with far-reaching 2x 400 mm aluminium spring arms for ergonomic positioning. 1840 lm at ~10 W in 5700K, Ra >90, IP40. Incl. 100-240V power supply and table clamp.

Net
€326.13
excl. VAT
Item L2W-120610-01
Manufacturer no. 120610-01
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The UNILED II articulated-arm LED light brings 1840 lm of homogeneous, shadow-free and glare-free area lighting exactly where it is needed at the workstation, via high-grade aluminium spring arms and 3D joints. Luminaire width 298 mm.

Your benefits

  • Far-reaching 2x 400 mm aluminium spring arms for ergonomic, precise positioning.
  • 1840 lm at ~10 W, about 184 lm/W luminous efficacy in 5700 K daylight white.
  • Very good Ra >90 colour rendering for true-to-life colour recognition.
  • Homogeneous, shadow-free and glare-free illumination thanks to opal-white glare control.
  • Supplied including 100-240V AC power supply and table clamp.
  • Compact short luminaire head for narrow work areas.

Applications

Proven in industry, laboratories, quality assurance, workshops and in the jewellery and watchmaking trades, for which the series was originally developed.

Technical data

ModelUNILED II articulated arm
Power~10 W
Luminous flux1840 lm
Light colour5700K 3-step MacAdam
Colour rendering (Ra)>90
Beam angle100°
Supply voltage24V DC ± 10%
Power supply100-240V AC unit included
ConnectionM12 A-coded
Protection rating (IP)IP40
Protection classIII
Operating temperature-10 °C to +60 °C
Service life>100,000 h (L80/B10)
Housing materialaluminium / plastic
Cover materialmatt plastic
Luminaire width298 mm
Articulated arms2x 400 mm
Weight3650 g
Risk group (DIN EN 62471)exempt group
CertificationsCE, UKCA
Mounting accessorytable clamp included
Made inGermany
ManufacturerLED2WORK
Manufacturer Nr.120610-01
HS-Code94054239
GPSR manufacturer informationLED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of articleNew
Article authenticityOriginal product
Country of ManufactureGermany
ESD versionTEC
NormDIN EN 62471
Luminous flux (lumen)1840 lm
Power (W)10 W
Colour temperature5700K
Mounting typeArticulated arm, Table clamp
Operating voltage100-240 V
Protection class (IP)IP40
