UNILED II articulated-arm light dimmable, width 298 mm, 5700K 10W 100-240V - LED2WORK 120610-02
UNILED II articulated-arm LED light, luminaire width 298 mm, with far-reaching 2x 400 mm aluminium spring arms for ergonomic positioning. 1840 lm at ~10 W in 5700K, Ra >90, IP40 with internal dimming and memory function. Incl. 100-240V power supply and table clamp.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The UNILED II articulated-arm LED light brings 1840 lm of homogeneous, shadow-free and glare-free area lighting exactly where it is needed at the workstation, via high-grade aluminium spring arms and 3D joints. Luminaire width 298 mm with internal dimming and memory function.
Your benefits
- Far-reaching 2x 400 mm aluminium spring arms for ergonomic, precise positioning.
- 1840 lm at ~10 W, about 184 lm/W luminous efficacy in 5700 K daylight white.
- Very good Ra >90 colour rendering for true-to-life colour recognition.
- Homogeneous, shadow-free and glare-free illumination thanks to opal-white glare control.
- Supplied including 100-240V AC power supply and table clamp.
- Internal dimmer with memory function for individual brightness.
Applications
Proven in industry, laboratories, quality assurance, workshops and in the jewellery and watchmaking trades, for which the series was originally developed.
Technical data
| Model | UNILED II articulated arm |
|---|---|
| Power | ~10 W |
| Luminous flux | 1840 lm |
| Light colour | 5700K 3-step MacAdam |
| Colour rendering (Ra) | >90 |
| Beam angle | 100° |
| Supply voltage | 24V DC ± 10% |
| Power supply | 100-240V AC unit included |
| Connection | M12 A-coded |
| Protection rating (IP) | IP40 |
| Protection class | III |
| Operating temperature | -10 °C to +60 °C |
| Service life | >100,000 h (L80/B10) |
| Housing material | aluminium / plastic |
| Cover material | matt plastic |
| Luminaire width | 298 mm |
| Articulated arms | 2x 400 mm |
| Weight | 3650 g |
| Risk group (DIN EN 62471) | exempt group |
| Certifications | CE, UKCA |
| Mounting accessory | table clamp included |
| Made in | Germany |
| Manufacturer | LED2WORK |
| Manufacturer Nr. | 120610-02 |
| HS-Code | 94054239 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| ESD version | TEC |
| Norm | DIN EN 62471 |
| Control and dimming | Dimmable |
| Luminous flux (lumen) | 1840 lm |
| Power (W) | 10 W |
| Colour temperature | 5700K |
| Mounting type | Articulated arm, Table clamp |
| Operating voltage | 100-240 V |
| Protection class (IP) | IP40 |
