FIELDLED EVO surface 280x96 mm machine light 19W, 100°, M12 front, IP67/IP69K - LED2WORK 153010-01

Images are examples, some edited with AI. The technical data are authoritative. AI notice

FIELDLED EVO surface 280x96 mm machine light 19W, 100°, M12 front, IP67/IP69K - LED2WORK 153010-01

Name: FIELDLED EVO surface 280x96 mm machine light 19W, 100°, M12 front, IP67/IP69K - LED2WORK 153010-01
Brand: LED2WORK
SKU: L2W-153010-01
Price: 204.78 EUR
Availability: InStock

LED2WORK ✓ Original product Brand new Made in Germany

High-output LED machine light as a surface-mounted light with 3000 lm from 19 W for even, glare-free lighting of large machines. Safety glass, a metal housing and IP67/IP69K protect against chips and coolant.

Net

€204.78

excl. VAT

Item L2W-153010-01

Manufacturer no. 153010-01

Question about this item

Datasheet (PDF) User manual 5 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

For even, flicker- and glare-free lighting of large plant, the FIELDLED EVO surface delivers 3000 lm from around 19 W with microprism glare control, ideally for harsh settings such as metal machining.

Key benefits

High output of 3000 lm at around 19 W, 155 lm/W
Microprism glare control for flicker- and glare-free light
IP67/IP69K rating against chips, dust and coolant
Aluminium metal housing with shatterproof toughened safety glass (ESG)
Vibration-resistant at 10 to 55 Hz and shock-resistant up to 50 g
M12 connection on the front, reverse-polarity-safe at 24V DC

Applications

Lighting of machine tools and large plant, ideally in metal machining. The surface-mounted light retrofits into almost any machine tool.

Technical data

Model	FIELDLED EVO surface, M12 front
Design	surface-mounted LED machine light
Light source	SMD LED
Power	~19 W
Luminous flux	3000 lm
Luminous efficacy	155 lm/W
Light colour	5700K 3-step MacAdam
Colour rendering (Ra)	>85
Supply voltage	24V DC ± 10%
Connection	M12 A-coded, front
Protection rating	IP67/IP69K
Protection class	III
Glare control	microprisms
Beam angle	100°
Operating temperature	-30 °C to +60 °C
Service life	> 100,000 h (L80/B10)
Vibration resistance	10 to 55 Hz (amplitude 0.35 mm)
Shock resistance	up to 50 g
Housing material	aluminium
Cover material	ESG (safety glass), shatterproof
Dimensions (H x W)	30 mm x 96 mm, length: 280 mm
Weight	1180 g
Risk group (DIN EN 62471)	exempt group
Dimmable	optional via accessory
Mounting accessories	optional, 2 screw channels for M5 on the rear
Certifications	CE, UKCA, ETL Listed (5003529)
Made in	Germany
Manufacturer	LED2WORK
Manufacturer Nr.	153010-01
HS-Code	94054239
GPSR manufacturer information	LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com
Condition of article	New
Article authenticity	Original product
Country of Manufacture	Germany
Norm	DIN EN 62471
Control and dimming	Dimmable
Luminous flux (lumen)	3000 lm
Power (W)	19 W
Colour temperature	5700K
Mounting type	Surface-mounted
Operating voltage	24 V
Protection class (IP)	IP69K
