The FIELDLED EVO surface-mounted light gives large machine work areas uniform, glare-free and flicker-free illumination. It delivers 13400 lm at around 86 W with a 5700 K light colour and Ra >85 for high-contrast working light. Safety glass and an aluminium housing rated IP67/IP69K reliably keep out chips and coolant, while the front-side M12 connection makes retrofitting straightforward.
FIELDLED EVO surface-mount machine light 702x150 mm 86W IP69K front-side - LED2WORK 153510-01
LED2WORK Original product
Net price (excl. VAT)
€506.70
Item L2W-153510-01
Manufacturer no. 153510-01
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.153510-01
Country of originGermany
Customs tariff number94054239
ConditionNew
Article
L2W-153510-01
Frequently Bought Together
- This Item: €506.70
- LED Segment Ring Light pure white 6000 K, working distance 50-800 mm, outer Ø 130 mm - Starlight RL12-18f-S40 PW €706.64
- D70-R195 downlight - Glamox 9E265AD4D1 As low as €147.00Show details
Total price
The FIELDLED EVO surface-mount machine light lights up the large interior work areas of machine tools and production equipment uniformly, without glare or flicker. With 13400 lumens at roughly 86 W it puts high-contrast light exactly where metal cutting demands maximum visual performance.
Key benefits
- 13400 lm luminous flux at only about 86 W, with 155 lm/W efficacy for low energy use.
- IP67/IP69K rating, safety glass and an aluminium housing withstand chips, coolant and high-pressure washdown.
- Micro-prism glare control plus 5700 K at Ra >85 deliver fatigue-free, high-contrast working light.
- Reverse-polarity-safe front-side M12 connection (A-coded) for a fast, secure 24V DC machine-power connection.
- Over 100,000 h service life (L80/B10), shock-resistant to 50 g and vibration-resistant for harsh continuous duty.
Technical data
- Model: FIELDLED EVO front-side, M12 Surface-mounted light
- Design: LED surface-mounted light for machines
- Light source: SMD LED
- Power: approx. 86 W
- Luminous flux: 13400 lm
- Luminous efficacy: 155 lm/W
- Light colour: 5700 K (3-step MacAdam)
- Colour rendering: Ra >85
- Beam angle: 100°
- Glare control: micro-prisms
- Supply voltage: 24V DC ±10%
- Connection: M12 A-coded, front-side
- Protection rating: IP67/IP69K
- Protection class: III
- Operating temperature: -30 °C to +60 °C
- Service life: > 100,000 h (L80/B10)
- Vibration resistance: 10 to 55 Hz (amplitude 0.35 mm)
- Shock resistance: up to 50 g
- Housing material: aluminium
- Cover material: toughened safety glass, splinter-free
- Dimensions: 702 x 150 x 30 mm
- Weight: 4.0 kg
- Risk group (DIN EN 62471): exempt group
- Certifications: CE, UKCA, ETL Listed (5003529)
- Dimmable: optional via accessory
- Made in: Germany
Applications
Designed for interior lighting of machine tools, machining centres and large-volume production equipment, especially in metal cutting and harsh production environments. The light retrofits into almost any machine tool via rear M5 screw channels; optional brackets and dimming accessories are available.
| Manufacturer Nr. | 153510-01 |
|---|---|
| Manufacturer | LED2WORK |
| Country of Manufacture | Germany |
| Weight | 4.000000 |
| HS-Code | 94054239 |
| GPSR manufacturer information | LED2WORK GmbH, Stuttgarter Straße 13 A, 75179 Pforzheim www.led2work.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
