DIN rail power supply 120W 24V DC for LED2WORK lights - LED2WORK 210100-09

This 24V DC switching power supply feeds LED2WORK 24V DC lights with higher power demand and mounts directly onto a DIN rail via screw terminals. In an enclosed industrial design, it delivers up to 120 W of stable output.

Your benefits

• 120 W of stable 24V DC output for LED2WORK lights
• Wide input voltage range from 88 to 264V AC
• Protection against short circuit, overload, over-voltage and over-temperature
• Easy DIN rail mounting via screw terminals
• High efficiency of 91 % at full load
• Dimmable in combination with PWM dimmers from LED2WORK

Technical data

• Model: Constant-voltage power supply
• Type: DIN rail switching power supply
• Nominal output voltage: 24V DC
• Max. output power: 120 W
• Output current: 5000 mA
• Input voltage: 88 to 264V AC
• Input frequency: 47 to 63 Hz
• Efficiency at full load: 91 %
• Ambient temperature: -25 °C to +70 °C
• Over-temperature protection: 95 °C ± 10 °C
• Dimensions: 40 mm x 125.2 mm x 113.5 mm
• Weight: 600 g
• Protective devices: short-circuit, overload, over-voltage, over-temperature protection
• Certifications: CE, CB, UKCA, UL508 approved, ITE EN/UL/IEC 60950

Applications

For powering LED2WORK 24V DC lights in the control cabinet and in the machine. Not suitable for no-load operation. When selecting, check the power consumption and connection ratings of your luminaire.
