DIN rail power supply 24V DC, 91.2 W, protection class II - LED2WORK 210100-14

This 24V DC fixed-voltage switching power supply feeds LED2WORK luminaires with a constant voltage and is fixed via screw terminals to a standard TS35 DIN rail. The wide input range and protective functions make it a reliable industrial supply inside the control cabinet.

Key benefits

• Suits all LED2WORK 24V DC luminaires
• Maximum output 91.2 W at 3800 mA
• Wide input range 90 to 264V AC (125 to 375V DC)
• Built-in overvoltage and overtemperature protection
• Enclosed design for DIN rail mounting (TS35 DIN Rail)
• Dimmable with LED2WORK PWM dimmers

Technical data

• Model: constant-voltage power supply
• Design: DIN rail switching power supply, 24V DC, TS35 DIN Rail mounting
• Nominal output voltage: 24V DC
• Max. output power: 91.2 W
• Output current: 3800 mA
• Input voltage: 90 to 264V AC (125 to 375V DC)
• Protection class: II
• Dimensions: 91 mm x 90 mm x 56 mm
• Weight: 350 g
• Certifications: CE
• Dimmable: with LED2WORK PWM dimmers

Applications

For powering LED2WORK 24V DC machine and workplace lights from the control cabinet. Please check the power consumption and connection ratings of the luminaire before selection.
