Plug-in power supply 40W, 24V DC with EU/US/UK/AU adapters - LED2WORK 210100-17

One power supply for every market: this plug-in unit feeds LED2WORK 24V DC luminaires up to 40 W and adapts to outlets in Europe, the USA, the UK and Australia via interchangeable AC plugs.

Key benefits

• Four supplied AC plugs (EU, US, UK, AU) for worldwide use.
• Universal 90 to 264V AC input, compliant with current US and EU energy regulations.
• Up to 88 % efficiency and very low no-load consumption below 0.075 W.
• Reverse-polarity-proof M12-A connector for fast commissioning without miswiring.
• Protection class II with overload and overvoltage protection, LED indicator when powered.
• Wide -30 °C to +70 °C temperature range, flame-retardant plastic housing.

Technical data

• Model: constant-voltage power supply
• Output voltage: 24V DC
• Max. output power: 40 W
• Output current: 1670 mA
• Input voltage: 90 to 264V AC, 47 to 63 Hz
• Efficiency at full load: 88 %
• Connection to luminaire: M12 socket, A-coded
• Protective features: overload and overvoltage protection
• Ambient temperature: -30 °C to +70 °C
• Humidity: 20 to 90 % (non-condensing)
• Dimensions: 48.4 x 40 x 94 mm
• Weight: 300 g
• Certifications: UL/cUL, TÜV EN, EN CB IEC 62368-1, FCC, CE

Applications

Power supply for LED2WORK 24V DC machine and workplace lights with M12 connection, especially for international machine building and equipment shipped to several countries.

Scope of delivery: constant-voltage plug-in power supply with US, EU, UK and AU AC adapters plus a straight M12-A output and outgoing cable with M12-A connector.
