Funnelet to Complement Cir-Kit Pad Frames - PACE 1347-0053

The PACE Cir-Kits contain frames with replacement traces and pads, such as the Track Pad Frame and Dip Pad Frame. So that a newly applied pad also closes off the hole cleanly, a funnelet such as the 1347-0053 is set in addition and connects both sides.

Benefits

• Adds a hole barrel to replacement pads from the Cir-Kit frames
• Listed in the PACE catalog as an accessory of all three Cir-Kit versions
• Processed with the Cir-Kit setting tools

Specifications

Applications

• Pad repair with Cir-Kit frames
• Rebuilding through-hole solder joints
