High-precision guide rails BSHP
High-precision ball rail systems BSHP
High-precision ball rails of the Bosch Rexroth BSHP series form the fixed raceway of the ball rail guidance system. Manufactured from hardened carbon steel with precision-ground raceways, together with the BSHP runner blocks they ensure high guidance accuracy and consistently smooth running over long travel distances.
esd.equipment supplies BSHP ball rails in sizes 15 to 65 and in numerous lengths and hole patterns (bolted from above or below, with or without cover). Accuracy classes H, P, SP and UP cover everything from standard to high-precision requirements.
BSHP ball rails - overview
| Size | Bolting | Accuracy | Material |
|---|---|---|---|
| 15 / 20 | from above (SNS) | H / P / SP | hardened carbon steel |
| 25 / 30 | from above / below | H / P / SP / UP | hardened carbon steel |
| 35 / 45 | from above / below | H / P / SP | hardened carbon steel |
| 55 / 65 | from above | H / P | hardened carbon steel |
Typical applications: Machine tools and special-purpose machines, measuring and test technology, handling and gantry systems, semiconductor and electronics manufacturing, and all applications with high demands on guidance accuracy and repeatability.
