Chisel tip 1.0 x 0.6 mm from the QU911G series for the 9018M and 9018BMT robot soldering tools. The narrow edge puts heat exactly on small pads and single pins without warming the neighbours. For series soldering of boards, connectors and stranded wires in automatic operation.
Lötspitze meißelförmig 1,0 x 0,6mm für Lötroboter-Tools 9018M, 9018BMT - Quick QU911G-10D
QUICK
Original product
Net price (excl. VAT)
€9.48
Item
QCK-QU911G-10D
Manufacturer no.
QU911G-10D
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.QU911G-10D
ConditionNew
Article
QCK-QU911G-10D
Frequently Bought Together
-
This Item:
€9.48
-
Kartuschenlötspitze für TS8, gerade, meißelförmig stumpf 1,6 mm breit x 0,5 mm, 5 mm Lot-benetzt - Quick TSS08-1.6D
€15.08
-
ESD soldering tip chisel 2.4 mm for TS1200 - Quick TSS02-2.4D
€12.56
Total price
In robot operation the tip geometry decides how much heat reaches a joint and what happens next to it. The QU911G-10D is a chisel tip measuring 1.0 x 0.6 mm, which lets it meet small pads and single pins accurately without heating the surrounding area more than necessary.
What the tip does
- Chisel shape 1.0 mm wide, so the edge lies flat on pad and lead and transfers heat in a short time.
- Straight design matching the fixed axis position in the robot, keeping the approach to each joint predictable.
- QU911G series, designed for repeatable joints and long service life in continuous operation.
- RoHS compliant and therefore unrestricted in lead-free series production.
Technical data
| Type | QU911G-10D |
| Series | QU911G |
| Tip shape | chisel |
| Size | 1.0 x 0.6 mm |
| Tip width | 1.0 mm |
| Design | straight |
| RoHS compliant | Yes |
| Tools | 9018M, 9018BMT |
| Brand | Quick |
Application and compatibility
Fits the 9018M and 9018BMT robot soldering tools and with them the QUICK ET9181 SEMI-AUTO, 9594FYA, ET9494E, 9584EYA and ET9494F-A machines as well as further models of the range. For wider joints the same series offers the QU911G-16D at 1.6 x 0.6 mm. Being a wear part, the size in use is worth stocking twice. Scope of delivery: one soldering tip.
| Manufacturer Nr. | QU911G-10D |
|---|---|
| Manufacturer | Quick |
| GPSR manufacturer information | Bräunlich GmbH Am Heideberg 26, DE 06886 Lutherstadt Wittenberg, www.braeunlich-gmbh.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
