Heizkörper H616A für Station 861DW - Quick QUHK861DW

The 861DW works with 1000 W of heating power, and that figure is exactly what lets it bring larger parts and ground pads up to temperature quickly. When the output fades, the original H616A restores the full working range of 100 to 500 °C.

What the element does

• 1000 W, more than eight times the H617 of the smaller 860DA, so air temperature climbs quickly under load.
• The full station range of 100 to 500 °C is supported, keeping lead free alloys with a high liquidus point workable.
• Fast heat up shortens the time an assembly spends under hot air, which spares the neighbouring components.
• Made to fit the 861DW, so mounting and contacts need no adaptation.
• At 0.1 kg shipping weight, stocking one pays where a station failure would block incoming repairs.

Technical data

Applications

Repair of the 861DW in service, workshop and production, for example after falling output, long heat up times or temperature sag in continuous use. The station is used for rework, desoldering and handling SMD components.

Scope of delivery and compatibility

One H616A heating element for the Quick 861DW. The 860DA takes the H617 at 120 W instead, and the two parts cannot be exchanged for one another.
