Regelplatine für Lötbad 100-4C - Quick QURP100-4C
Control board for the Quick 100-4C solder bath, handling temperature sensing and heater control of the pot. Genuine assembly in a 280 x 180 mm format, the larger of the two boards used across this pot range. Needed when the pot no longer holds its setpoint or the display shows implausible readings.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A solder pot is only as good as its temperature control. When the control fails, the pot swings around the setpoint or heats without limit. The genuine board for the 100-4C replaces the control as one complete assembly of 280 x 180 mm.
Features
- Factory assembly from Quick, designed for the 100-4C pot specifically.
- Format 280 x 180 mm, clearly larger than the 220 x 140 mm board of the 100-6C, so the two are not interchangeable.
- A light assembly at 0.04 kg, and the power section of the pot stays untouched during the change.
- Restores setpoint control without replacing pot, heater or housing.
Applications
Repair of controlled solder pots in cable assembly, tinning work and service workshops. The usual trigger is a pot running too hot, staying too cold, or a display that no longer matches the real state of the bath.
Technical data
| Brand | Quick |
|---|---|
| Part number | QURP100-4C |
| Component | control board |
| Matching unit | Quick 100-4C solder bath |
| Equipment group | controlled solder pot |
| Weight | 0.04 kg |
| Dimensions, supplier data | 280 x 180 mm |
| Manufacturer | Quick |
| Manufacturer Nr. | QURP100-4C |
| GPSR manufacturer information | Bräunlich GmbH Am Heideberg 26, DE 06886 Lutherstadt Wittenberg, www.braeunlich-gmbh.com |
| Condition of article | New |
| Article authenticity | Original product |
Scope of delivery
One control board for the 100-4C solder bath, without sensor and without housing parts. The 100-6C takes its own smaller board. Fitting is done with the unit isolated from the mains by qualified personnel.
