Kartuschenlötspitze für TS8, gerade, schlank verlängert, meißelförmig stumpf 2,4 mm breit x 0,7 mm, 4 mm Lot-benetzt - Quick TSS08-2.4D01

Wide blades usually fail on space, not on heat capacity. The TSS08-2.4D01 combines the 2.4 mm contact face with a slim extended neck, so the blade also reaches leads that sit behind tall parts or down inside a housing.

Key points

• Slim extended shape brings the blade to deep seated pins without the tip body fouling anything.
• Blade width 2.4 mm, the same face as the short TSS08-2.4D, so larger pad rings are still heated over their full area.
• Blade thickness 0.7 mm, slimmer than the short version, which helps between closely spaced leads.
• Tinning over 4 mm carries the reservoir across several joints.
• Thermocouple in the cartridge and a chip holding the calibration value, so the station shows the real tip temperature.

Specifications

Use and scope of delivery

For repairs on installed assemblies, on connectors and terminals inside equipment, and on through hole parts between tall neighbours. Where space is open and more heat reserve is wanted, the short TSS08-2.4D suits better. The tip fits the QUELKTSS80A iron of the Quick TS8 and TS8+ stations. Supplied as one cartridge tip without iron or station.
