Grip clamp attachment for insertion and pull tests up to 500 N, 2 pieces - SAUTER AC 09
The SAUTER AC 09 is a steel grip clamp attachment for insertion and pull tests up to 500 N. The screw clamp holds samples up to 6 mm clamping width with an 8 mm span and mounts via an M6 threaded hole. Supplied as 2 pieces, suitable for SAUTER force gauges of the FC, FH and FL series and the TVL, TVO and TVS test stands.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Insertion and pull tests need the sample held firmly while the force gauge records the force. The SAUTER AC 09 grip clamp attachment secures the sample between screw-tightened steel jaws and is rated for tensile and compressive forces up to 500 N. Two clamps are included.
Advantages
- Screw clamp with jaws: holds the sample securely under tensile or compressive forces up to 500 N
- For small samples: maximum clamping width 6 mm with 8 mm span
- Simple mounting: force transmission via M6 threaded hole
- Compact design: 120 x 55 x 30 mm fully assembled
- Versatile: for SAUTER force gauges FC, FH and FL as well as the TVL, TVO and TVS test stands
Ordering note
When ordered individually, clamps may need adapters for mounting. Please tell us which instrument the clamp will be used with so that the matching adapters can be supplied.
Conformity and origin
EAN 4045761493186.
Technical data
| Tensile/compressive force (max.) | 500 N |
|---|---|
| Maximum clamping width | 6 mm |
| Maximum span | 8 mm |
| Material | steel |
| Mounting - force transmission | M6 threaded hole |
| Dimensions fully assembled (W x D x H) | 120 x 55 x 30 mm |
| Net weight | 0.36 kg |
| Pieces per sales unit | 2 |
| Weight | 0.36 kg |
| Manufacturer | Sauter |
| EAN | 4045761493186 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
Scope of delivery
2 SAUTER AC 09 grip clamp attachments.
