Digital Force Gauge Haken - SAUTER FC 50
The SAUTER FC 50 is a digital force gauge with an internal load cell for tensile and compressive forces up to 50 N at 0,01 N readout. Peak-hold, a limit function and RS-232 plus USB are standard. It ships in a sturdy carrying case.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The SAUTER FC 50 measures tensile and compressive forces up to 50 N with 0,01 N readout through an integrated load cell. A reversible backlit display and selectable units (N, kgf, ozf and lbf) make it a versatile hand-held gauge for laboratory, production and maintenance work.
Benefits
- Fine resolution: 50 N range at 0,01 N readout.
- Tension and compression: both force directions in one instrument.
- Repeatable accuracy: tolerance 0,3 % of Max, overload protection 150 % of Max.
- Peak and live value: peak-hold keeps the maximum, the track function shows the live reading.
- Limit function: upper and lower limits with audible and visual signalling.
- Internal memory: up to 500 readings stored in the instrument.
- Test-stand ready: mounts on any SAUTER test stand up to 5 kN.
- Interfaces: USB device and RS-232 as standard.
Applications
Typical fields of use for the FC 50 include test laboratories, research and development, the automotive industry, maintenance and servicing, and plastics engineering.
Compliance
EAN 4045761160859. Customs code 90248000.
Technical data
| Range (Max) | 50 N |
|---|---|
| Readout (d) | 0,01 N |
| Tolerance | 0,3 % of Max |
| Overload protection | 150 % of Max |
| Sampling rate | 1000 Hz |
| Force directions | tension and compression |
| Load coupling | hook |
| Interfaces | RS-232 and USB device as standard |
| Housing | metal |
| Dimensions (assembled) | 140 x 70 x 34 mm |
| Net weight | 0,95 kg |
| Operating temperature | -10 to 40 °C |
| Power | NiMH battery and mains adapter (100 V - 240 V) |
| Weight | 1.2 kg |
| Manufacturer | Sauter |
| Manufacturer Nr. | FC 50 |
| EAN | 4045761160859 |
| HS-Code | 90248000 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| Material | Metal |
| Display type | LCD |
| Interface | RS-232, USB device |
