The SAUTER CB 150-3Q1 is a bending and shear beam load cell in stainless steel for rated loads up to 150 kg. As an OIML R60 class C3 component with 3000 divisions, it suits platform, hopper and floor scales in demanding conditions.
Load Cell 150 kg - SAUTER CB 150-3Q1
SAUTER
Original product
Net price (excl. VAT)
€180.32
Item
KER-CB 150-3Q1
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
EAN4045761220706
Country of originSpain
Customs tariff number84239010
ConditionNew
Article
KER-CB 150-3Q1
Frequently Bought Together
-
This Item:
€180.32
-
Load Cell 2 kg - SAUTER CS 2-Y1
€270.48
-
Load Cell 150 kg - SAUTER CP 150-3P2
€63.50
Total price
For weight and compression-force measurement in demanding conditions, the SAUTER CB 150-3Q1 carries up to 150 kg rated load: a bending and shear beam load cell in stainless steel, legal-for-trade as an OIML R60 class C3 component.
Benefits
- Legal-for-trade component: OIML R60 class C3, 3000 divisions (e), Y value 10000
- Durable housing: stainless steel for demanding environments
- Wide temperature range: use from -30 to 70 deg C
- Ready to fit: 3 m cable, 4-wire connection, compression loading
- Optional: accuracy class OIML R60 C6 or Ex version on request
Technical data
- Rated load (Max): 150 kg
- Accuracy class: OIML R60 class C3, 3000 e, Y value 10000
- Design: bending and shear beam load cell
- Material: stainless steel
- Force direction: compression
- Ambient temperature: -30 to 70 deg C
- Dimensions (diameter x height): 41,5 x 120 mm
- Cable length: 3 m
- Connection: 4-wire
- Net weight: 0,50 kg
- On request: accuracy class OIML R60 C6 or Ex version
Applications
Suited to platform, hopper and floor scales and other weighing devices in industry and manufacturing, the chemical industry, food and pharma, building materials, and logistics and packaging.
Compliance and origin
OIML R60 class C3. EAN 4045761220706, customs tariff number 84239010, country of origin Spain.
| Manufacturer | Sauter |
|---|---|
| Country of Manufacture | Spain |
| EAN | 4045761220706 |
| Weight | 0.550000 |
| HS-Code | 84239010 |
| GPSR manufacturer information | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Article authenticity | Original product |
| Condition of article | New |
| Wägebereich max (g) | 150000.000000 |
| Position sensing | No |
