Load Cell 150 kg - SAUTER CS 150-3P1
The SAUTER CS 150-3P1 is an S-type weighing and force load cell for tension and compression up to 150 kg (1,5 kN). Its nickel-plated steel body reaches calibratable OIML C3 accuracy (3000 e) and connects via four wires to scales and test benches.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The SAUTER CS 150-3P1 captures tension and compression forces up to 150 kg (1,5 kN) and works as an S-type cell for hanging and hopper scales with limited installation space.
Benefits
- Tension and compression in one cell: captures forces up to 1,5 kN in both directions
- Calibratable accuracy: OIML class C3 with 3000 verification intervals (e)
- Corrosion-protected: nickel-plated steel body for industrial use
- Four-wire S-body: easy integration into hanging, hopper and tank scales
- Wide operating range: ambient temperature from -35 °C to 65 °C
Applications
The load cell is used in machine and plant engineering, testing and materials testing, conveyor and logistics systems, tank and silo weighing as well as in medical technology and research.
Compliance and origin
EAN 4045761221475, customs tariff code 90249000, country of origin China. EX version or accuracy class C4 available on request.
Technical data
| Weighing range (max) | 150 kg |
|---|---|
| Force range (max) | 1,5 kN |
| Force directions | tension and compression |
| Accuracy class (OIML) | C3 |
| Verification interval | 3000 e |
| Y value | 10000 |
| Connection | 4-wire |
| Cable length | 3 m |
| Operating temperature | -35 °C to 65 °C |
| Material | nickel-plated steel |
| Net weight | 0,55 kg |
| Weight | 0.65 kg |
| Manufacturer | Sauter |
| EAN | 4045761221475 |
| HS-Code | 90249000 |
| GPSR manufacturer information | KERN & SOHN GmbH, Ziegelei 1, DE-72336 Balingen-Frommern, www.kern-sohn.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | China |
| Wägebereich max (g) | 150000 |
