Soldering tip bevelled 60° 1.78 x 14.2 mm STTC series - Metcal STTC-047
Replaceable cartridge with bevelled geometry and integrated SmartHeat heater for the Metcal MX-500, MX-5000 and MX-5200 systems. The fixed tip temperature of 357 °C keeps temperature sensitive components and boards within a safe range. The tip measures 1.78 x 14.2 mm and needs no calibration or temperature setting on the unit.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Work on densely populated assemblies calls for a tip with a defined geometry and a stable temperature. The Metcal STTC-047 is an STTC series soldering cartridge with a bevelled tip of 1.78 x 14.2 mm and a tip temperature of 357 °C.
Benefits
- Bevelled geometry 1.78 x 14.2 mm for controlled heat transfer
- Fixed tip temperature of 357 °C through SmartHeat technology, no calibration required
- Heater and sensor sit inside the cartridge, so a tip change takes seconds
- Fits the MX-H1-AVA and MX-RM3E hand pieces
- Runs on the MX-500, MX-5000 and MX-5200 systems
Applications
Suited to drag soldering of SOIC and QFP packages, fine-pitch rows and removal of excess solder.
Compatibility and scope of delivery
The cartridge fits the Metcal MX-H1-AVA and MX-RM3E hand pieces and runs on the MX-500, MX-5000 and MX-5200 power units. Delivery includes one STTC-047 soldering cartridge.
Technical data
| Item no. | WL13886 |
|---|---|
| Manufacturer | Metcal |
| Manufacturer item no. | STTC-047 |
| Product series | STTC series |
| Tip shape | bevelled |
| Tip alignment | sloped |
| Tip angle | 60° |
| Tip width | 1.78 mm |
| Tip length | 14.2 mm |
| Tip temperature | 357 °C |
| Matching hand piece | MX-H1-AVA, MX-RM3E |
| Compatible systems | MX-500, MX-5000, MX-5200 |
| Order unit | piece |
| Weight | 0.1 kg |
| Weight | 0.100000 |
| Manufacturer Nr. | STTC-047 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Condition of article | New |
| Article authenticity | Original product |
| Tip diameter/width [mm] | 1.780000 |
| Soldering tip shape | angeschrägt |
| Series | STTC |
