C-series chisel soldering tip 2.4 mm, 480 °C, for FE 50M, TCP and TCPS - Plato C-3040-9
Chisel-shaped C-series soldering tip, 2.4 mm wide, with a 480 °C tip temperature. It corresponds to the Weller PTB and fits FE 50M, TCP and TCPS irons. Made for lead-free hand soldering of pads, connectors and THT parts.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The C-3040-9 soldering tip puts a 2.4 mm chisel edge on FE 50M, TCP and TCPS soldering irons. Its 480 °C tip temperature suits lead-free solder and joints that draw a lot of heat.
Benefits in use
- 2.4 mm chisel: good heat transfer to pads, component leads and small ground planes
- 480 °C tip temperature: enough reserve for lead-free soldering
- Straight C-series design: familiar handling, no retraining
- Corresponds to the Weller PTB tip and replaces it directly
Compatibility
Fits the FE 50M, TCP and TCPS soldering irons on the Weller stations WTCPT, WTCPTD, WTCPTFE, WTCPN, WTCPS, TC201T and TC201FE.
Applications
Hand soldering in electronics production, repair and the lab, for example THT components, connectors and joints with medium thermal mass.
Technical data
| Tip series | C-series |
|---|---|
| Tip shape | chisel |
| Tip width | 2.4 mm |
| Tip orientation | straight |
| Tip temperature | 480 °C |
| Matching handpiece | FE 50M, TCP, TCPS |
| Corresponds to | Weller PTB |
| Sales unit | 1 piece |
| Weight | 0.001 kg |
| Manufacturer | Plato |
| Manufacturer Nr. | C-3040-9 |
| HS-Code | 85159080 |
| GPSR manufacturer information | TECHSPRAY ITW, Saffierlaan 5, NL-2132 Hoofddorp, www.techsprayeu.com |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Spain |
Scope of delivery
1 soldering tip C-3040-9.
