Extraction unit ACD 400.1 for gases, vapours and odours, activated carbon - ULT 0401.0-FQ.1.0
Where solvents, adhesives or cleaning media outgas, a particle filter alone does nothing. The ULT ACD 400.1 in drive version MD.17 controls the airflow steplessly up to 1,000 m³/h, with a nominal operating point of 300 m³/h at 2,500 Pa. Two A14 adsorption filter cassettes holding 14 kg of activated carbon each bind the odour and pollutant load, while an M5 filter mat retains coarse dust upstream.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Gases, vapours and odours from bonding, cleaning and coating processes can only be taken out of the air by adsorption. The ACD 400.1 is therefore built as a pure adsorption unit: an M5 filter mat holds back coarse dust, then two A14 adsorption filter cassettes with 14 kg of activated carbon each bind the molecular load. The filter design is matched to the nominal airflow of the unit so that contact time is long enough for good adsorption behaviour.
Benefits
- Two A14 adsorption cassettes in series with 28 kg of activated carbon in total, for long service life with solvent vapours
- EC fan with pressure reserve, 0.7 kW motor rating, up to 1,000 m³/h and a maximum vacuum of 2,600 Pa
- Stepless airflow control at the potentiometer, optionally with ecoflow CS to compensate automatically for rising filter load and a changing number of capture points
- Noise level below 60 dB(A) across the full control range from 50 to 100 percent air performance
- IP 54 protection, powder coated sheet steel housing on castors, 652 x 600 x 1,140 mm
- Two Ø 80 mm intake ports for two capture points, optical particle filter load indicator at the front, M12 interface at the rear
Applications
Bonding and laminating, pretreatment and cleaning, painting and printing, casting and potting. The highly purified clean gas can be returned to the workroom in recirculation mode, so no heat is lost. Recirculation is not permitted for carcinogenic, mutagenic or reprotoxic substances. In those cases the optional Ø 160 mm exhaust port is fitted on the outlet side and the clean gas is ducted into a central exhaust system.
Compatibility and scope of delivery
The unit comes with filter configuration A28: change frame with M5 filter mat (ULT 4-01006), M5 filter mat as a spare (ULT 4-00210) and two A14 adsorption filter cassettes (ULT 4-00861). For gas mixtures ULT offers configuration AC39 with two AC19 cassettes of 19 kg activated carbon and chemisorbent each, and C50 with two C25 cassettes of 25 kg chemisorbent each. Capture elements such as the Alsident System 75 and System 100 extraction arms, DN 80 and DN 100 hoses and mounting brackets are ordered separately.
Technical data
| Item number | WL15495 |
|---|---|
| Model | ACD 400.1 MD.17 |
| Manufacturer | ULT |
| Manufacturer item number | ACD 0401.0-FQ.1.0 |
| Filter configuration | A28, M5 filter mat and 2 x A14 adsorption filter cassette |
| Dimensions (W x D x H) | 652 mm x 600 mm x 1,140 mm |
| Weight | approx. 100 kg |
| Order unit | Piece |
| Vacuum generator | EC fan |
| Motor rating | 0.7 kW |
| Volume flow max. | 1,000 m³/h |
| Vacuum max. | 2,600 Pa |
| Nominal operating point | 300 m³/h at 2,500 Pa |
| Rated voltage | 1~230 V |
| Rated frequency | 50/60 Hz |
| Rated current | 3.6 A |
| Noise level | below 60 dB(A) at 50 to 100 percent air performance |
| Protection class | IP 54 |
| Intake ports | 2 x Ø 80 mm, optional Ø 100 mm |
| Exhaust port | Ø 160 mm, optional |
| Mains cable | 3.0 m, CEE 7/7 |
| Weight | 100.000000 |
| Manufacturer Nr. | ACD 0401.0-FQ.1.0 |
| HS-Code | 84213925 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Power (W) | 700 W |
| Protection class (IP) | IP54 |
| Filter class | M5 |
| Airflow [m³/h] | 1000 |
| Max. vacuum [Pa] | 2600 |
| Sound pressure level [dB(A)] | 60 |
