Filter mat set M5/F7 for LRA Jumbo filter trolley - ULT 02.0.215
The set pairs a coarser M5 mat with a finer F7 mat and fills the change frame of the prefilter stage in the LRA Jumbo filter trolley. Rated to ISO 16890, M5 reaches ISO Coarse 85 percent and F7 reaches ISO ePM10 75 percent. Both mats form part of the complete cassette 02.1.200.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
A single prefilter mat is either too coarse and lets too much through or too fine and blinds off quickly. This ULT set therefore stages the M5 mat ahead of the F7 mat and fills the change frame of the prefilter stage in the LRA Jumbo filter trolley.
Benefits
- Two filter classes in one set, M5 as the coarse stage and F7 as the fine stage
- M5 rated ISO Coarse 85 % and F7 rated ISO ePM10 75 % to ISO 16890
- Staged separation raises the dust holding capacity of the prefilter pack
- Short mat change intervals keep the service life of the H13A combination filter cassette high
- Fits the ULT LRA Jumbo filter trolley
- Part of the complete combination filter cassette 02.1.200
- Supplied as a set, both mats on one order line
Applications
Scheduled servicing of mobile extraction with the LRA Jumbo at soldering and rework benches, and in production areas with a high dust load where prefilter stages are changed often. The mats retain sticky aerosols cooled down in the intake duct together with solder fume particles.
Compatibility and scope of delivery
Fits the ULT LRA Jumbo filter trolley and the 150, 220 and 250 series. Supplied as one set containing the M5 and F7 filter mats. In the LRA filter train the mats sit behind the expanded metal prefilter and ahead of the H13A combination filter cassette.
Technical data
| Item no. | WL20585 |
|---|---|
| Model | 02.0.215 |
| Manufacturer | ULT |
| Manufacturer item no. | 02.0.215 |
| Order unit | set |
| Filter type | prefilter |
| Filter classes | M5 and F7 |
| Filter mat M5 | ISO Coarse 85 % to ISO 16890 |
| Filter mat F7 | ISO ePM10 75 % to ISO 16890 |
| Position in the filter train | prefilter stage 2, behind the expanded metal prefilter |
| Device series | LRA Jumbo |
| Included in | combination filter cassette complete 02.1.200 |
| Weight | 0.1 kg |
| Weight | 0.100000 |
| Manufacturer Nr. | 02.0.215 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Norm | ISO 16890 |
| Filter class | M5/F7 |
