ESD surface resistance meter with data memory - Warmbier SRM 200

The Warmbier SRM 200 is a pocket surface resistance meter for measuring conductive and dissipative surfaces and for assessing electrostatic fields and charges. It covers the 10^3 to 10^12 ohm range and, thanks to internal memory and a USB interface, stores test data directly for evaluation on the PC, ideal for traceable documentation of EPA audits.

Key benefits

• Switchable test voltage 10/100 V for compliant checks across the 10^3 to 10^12 ohm range.
• Internal data memory with USB interface and readout software for complete PC documentation.
• Compact pocket format for mobile use across the work area.
• Bar electrode with conductive rubber for safe, even contact.
• Connection of two external electrodes for point-to-point and resistance-to-ground measurements.
• LCD display and conductive carrying case included.

Technical data

• Measuring range: 10^3 to 10^12 ohms
• Measuring voltage: 10 / 100 V switchable
• Display: LCD display
• Electrodes: bar electrode with conductive rubber, 2 external electrodes connectable
• Interface: USB
• Internal memory: yes
• Operation: rechargeable battery
• Standard: IEC 61340-4-5

Applications

• Measurement of ESD table mats, floor coverings and work surfaces.
• Documented EPA audits with data export to the PC.
• Point-to-point and resistance-to-ground measurements with external electrodes.

Scope of delivery

• Surface resistance meter SRM 200
• Conductive carrying case
• Grounding lead
• USB cable
• Readout software for stored test data
• Factory calibration certificate

Standards and compliance

Meets IEC 61340-4-5 for the measurement of surface and leakage resistance.
