Pair of soldering tips from the PTTC 800 series for the MX-PTZ thermal tweezers, blade-shaped, bent 30°, 3.5 x 12.1 mm. At a tip temperature of 485 °C the PTTC 800 series delivers enough power for ceramic substrates, large ground planes and lead free solder. The pair grips the component on both sides and releases both joints at once, which protects chip components with large ground planes, MELF bodies and small SOIC packages during removal.
Soldering tip pair blade-shaped bent 30° 3.5 x 12.1 mm PTTC 800 series - Metcal PTTC-808B
METCAL
Original product
Net price (excl. VAT)
€81.89
Item
WL27584
Manufacturer no.
PTTC-808B
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.PTTC-808B
ConditionNew
Article
WL27584
Frequently Bought Together
-
This Item:
€81.89
-
Soldering tweezer cartridges blade 20.5 mm bent 22°, PTTC 700 series - Metcal PTTC-706
€106.13
-
Soldering tip pair blade-shaped bent 22° 20.5 x 12.7 mm PTTC 800 series - Metcal PTTC-806
€106.13
Total price
Removing a component from both sides at the same time saves time and prevents one lead from being heated for too long. The PTTC-808B tip pair from the PTTC 800 series is blade-shaped, bent 30°, measures 3.5 x 12.1 mm and works at a tip temperature of 485 °C on the MX-PTZ thermal tweezers.
Benefits
- Tip pair blade-shaped, bent 30°, size 3.5 x 12.1 mm for a secure grip on the component
- Tip temperature of 485 °C held by SmartHeat induction heating without adjustment
- Heat from both sides releases both joints at once and shortens the contact time
- For the MX-PTZ thermal tweezers of the Metcal MX systems
- Supplied as a pair so that both arms share the same thermal behaviour
Technical data
| Item no. | WL27584 |
| Model | PTTC-808B |
| Manufacturer | Metcal |
| Manufacturer item no. | PTTC-808B |
| Sales unit | pair |
| Product series | PTTC 800 series |
| Tip width | 3.5 mm |
| Tip length | 12.1 mm |
| Tip shape | blade-shaped, bent 30° |
| Tip alignment | bent 30° |
| Tip temperature | 485 °C |
| Compatible handpiece | MX-PTZ |
| Weight | 0.100 kg |
Applications
Removal and placement of chip components with large ground planes, MELF bodies and small SOIC packages in repair, prototype work and production support in electronics manufacturing.
Compatibility and scope of delivery
The tip pair belongs to the PTTC 800 series and fits the MX-PTZ thermal tweezers of the Metcal MX systems. The sales unit is one pair, that is two matched tips.
| Manufacturer Nr. | PTTC-808B |
|---|---|
| Manufacturer | Metcal |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Position sensing | No |
