ESD Omniflex extraction arm 63 mm with large hood 350 x 212 mm - Oki EA1126

On a larger work surface or with several joints side by side a small nozzle no longer captures enough. The Oki EA1126 combines the 63 mm Omniflex arm with a large 350 x 212 mm hood, so solder fume is picked up reliably even from a greater distance. The fully conductive construction allows use inside an ESD protected area.

Benefits

• Air flow of around 140 m³/h, varying with the nozzle in use
• Large 350 x 212 mm hood covers wide working areas
• Ball and socket joints hold the set position without readjustment
• Working length and radius adjusted by adding or removing Omniflex segments, extensions in 300 mm steps
• Fully conductive material, ESD safe

Technical data

Applications

Fume and aerosol extraction at soldering, rework and bonding benches and in laboratories where a wider area has to be covered. The large hood suits assemblies with several joints worked in sequence.

Compatibility and scope of delivery

The arm is intended for extraction systems with a 63 mm connection from the Oki Omniflex and BVX range. Delivery covers the extraction arm with hood, extension segments and connecting hoses are available separately.

The fully conductive construction supports operation in an EPA according to IEC 61340-5-1.
