Solder fume extractor tip extraction up to 20 soldering irons 10000 Pa Zero Smog 20T - Weller T0053670699N

Extraction directly at the soldering iron captures the fume where it forms but needs a high vacuum because of the narrow suction line. The Weller Zero Smog 20T supplies up to 10000 Pa and serves up to 20 FE soldering irons in a central or decentralised installation.

Benefits

• Up to 6 Weller FE soldering irons connected directly, up to 20 via the 50 pipe system
• Electronically controlled maintenance-free turbine with a maximum vacuum of 10000 Pa
• Filter system with 99.95 percent separation efficiency to EN 1822 at 0.16 µm particle size
• Electronic logging of operating hours and filter contamination, USB connection and RS232 interface
• Four integrated castors and operation on a pipe system of up to 200 m

Technical data

Applications

Central solder fume extraction on production lines with many hand soldering benches, in repair centres and in training workshops. The four castors also allow decentralised use wherever soldering is currently taking place.

Compatibility and scope of delivery

Designed for Weller FE soldering irons with integrated extraction. Up to 6 irons connect directly, up to 20 require the 50 pipe system available as an accessory. The extractor is supplied with its filter set, soldering irons and pipe system are ordered separately.

The separation efficiency of 99.95 percent at 0.16 µm is stated to EN 1822.
