At 302 °C this cartridge stays well below common working temperatures and protects heat sensitive parts and substrates. The narrow long blade of 0.5 x 10 mm reaches between closely spaced leads. For rework on surface mounted components with MX-H1-AVA and MX-RM3E.
Rework tip blade-shaped long 0.5 x 10 mm, 302 °C - Metcal SMTC-560
METCAL
Original product
Net price (excl. VAT)
€123.82
Item
WL33253
Manufacturer no.
SMTC-560
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.SMTC-560
ConditionNew
Article
WL33253
Frequently Bought Together
-
This Item:
€123.82
-
Rework tip hoof-shaped 30° long 1.5 x 16.51 mm, 412 °C - Metcal SMTC-1167
€51.08
-
Rework tip quad for QFP 100, 412 °C, SMTC series - Metcal SMTC-144
€141.51
Total price
Heat sensitive assemblies cannot take 400 degrees yet still need a defined heat input. The Metcal SMTC-560 is a blade shaped rework cartridge of the SMTC series with a tip size of 0.5 x 10 mm and a tip temperature of 302 °C.
Benefits
- Low tip temperature of 302 °C for heat sensitive applications
- Narrow blade shape of 0.5 x 10 mm for closely spaced leads
- Tip length of 9.14 mm for controlled guidance at the joint
- Made for rework on surface mounted components
- Self regulating SmartHeat cartridge for the MX series
Technical data
| Item no. | WL33253 |
| Model | SMTC-560 |
| Manufacturer | Metcal |
| Manufacturer item no. | SMTC-560 |
| Order unit | Piece |
| Product series | SMTC series |
| Tip shape | Blade-shaped, long |
| Tip dimensions | 0.5 x 10 mm |
| Tip length | 9.14 mm |
| Tip temperature | 302 °C |
| Compatible hand piece | MX-H1-AVA, MX-RM3E |
| Weight | 0.1 kg |
Applications
Rework on temperature sensitive SMD parts, work on flexible circuits and plastic carriers, correction of single leads at small component spacing.
Compatibility and scope of delivery
The rework cartridge fits the MX-H1-AVA and MX-RM3E hand pieces of the Metcal MX series. Delivery covers one single cartridge without hand piece and without power unit.
| Manufacturer Nr. | SMTC-560 |
|---|---|
| Manufacturer | Metcal |
| Weight | 0.100000 |
| GPSR manufacturer information | OK International Ltd Eagle Close, Chandlers Ford GB-SO53 4NF Hampshire www.metcal.com |
| Article authenticity | Original product |
| Condition of article | New |
| Series | SMTC |
| Position sensing | No |
| Tip diameter/width [mm] | 0.500000 |
| Soldering tip shape | messerförmig |
Customers Who Bought This Item Also Bought
