Filter set H13A with G4 and M5 prefilters for JUMBO Filtertrolley Restauro - ULT 02.1.250
Complete replacement filter set for the JUMBO Filtertrolley 2.0 Restauro. It holds all three stages of the device build: Z-Line filter cassette G4 rated ISO Coarse 90 %, filter mat M5 rated ISO Coarse above 85 % and the H13A combination cassette made of an H13 HEPA filter to DIN EN 1822 plus an activated carbon bed. One service call restocks the unit completely.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Servicing a Restauro filter trolley means replacing three filter stages, not one. Set ULT 02.1.250 bundles exactly those items and brings a JUMBO Filtertrolley 2.0 Restauro back to full performance in a single pass.
Benefits
- Complete Restauro filter build, prestages and final stage under one order line
- H13A combination cassette combines an H13 particulate filter to DIN EN 1822 with an adsorption filter holding an activated carbon bed
- Particle separation rate of 99.95 % at the H13 stage as stated by the manufacturer
- Z-Line filter cassette G4 as the first stage, rated ISO Coarse 90 % to ISO 16890
- Filter mat M5 as the intermediate stage at ISO Coarse above 85 %, keeping the H13A cassette clear for longer
- One maintenance appointment instead of several partial changes, access through the intake plate without tools
Applications
Scheduled maintenance of mobile Restauro extraction units used in grinding and polishing as well as in the restoration and cleaning of art objects. The set is due when the particulate filter indicator on the unit lights up red or capture at the hood noticeably weakens.
Compatibility and scope of delivery
Fits the JUMBO Filtertrolley 2.0 Restauro, complete unit 1-00100, device variant VF RES Jumbo 2.0-BM.3.0. The LabCat K, complete unit 1-00051, uses the same filter build. The set is not intended for the MED filter trolley, whose final stage is the U15A combination cassette. The filter build is designed for the nominal operating point of 80 m³/h at 1,900 Pa (230 V). Scope of delivery: the three filter items 02.1.254, 02.0.256 and 02.1.251.
Technical data
| Item number | WL37027 |
|---|---|
| Model | ULT 02.1.250 |
| Manufacturer | ULT |
| Manufacturer item number | 02.1.250 |
| Filter type | filter set, three stages |
| Stage 1 | Z-Line filter cassette G4, ISO Coarse 90 % to ISO 16890 (ULT 4-00053, set of 10 4-00054) |
| Stage 2 | filter mat M5, ISO Coarse above 85 % to ISO 16890 (ULT 4-00231, set of 10 4-00232) |
| Stage 3 | combination filter cassette H13A, particulate filter H13 to DIN EN 1822 plus adsorption filter with activated carbon bed (ULT 4-00050) |
| Particle separation rate H13 stage | 99.95 % |
| Device series | JUMBO Filtertrolley 2.0 Restauro, identical build in LabCat K |
| Order unit | set |
| Weight | 0.100000 |
| Manufacturer Nr. | 02.1.250 |
| HS-Code | 84219990 |
| GPSR manufacturer information | ULT AG Am Göpelteich 1 DE-02708 Löbau www.ult.de |
| Condition of article | New |
| Article authenticity | Original product |
| Country of Manufacture | Germany |
| Filter class | H13 |
